TBS8520 Multiple inputs H.264/H.265 IPTV Transcoder

TBS8520 Multiple inputs H.264/H.265 IPTV Transcoder

TBS8520 Multiple inputs H.264/H.265 IPTV Transcoder

Regular price £4,100.00 + VAT

£4,920.00 inc VAT

TBS8520 is a professional hardware transcoding server, which is designed to be a highly scalable, easy to use and a cost effective IPTV headend server for developers and businesses to transcode (or convert) media files from their source format into the best-possible-quality streams to each user's specific device.

TBS8520 IPTV transcoder is equipped with 2 PCI express slots, which make it to be a flexible transcoder supporting IP, RF, HDMI or ASI inputs with the use of...

Contact us

TBS8520 is a professional hardware transcoding server, which is designed to be a highly scalable, easy to use and a cost effective IPTV headend server for developers and businesses to transcode (or convert) media files from their source format into the best-possible-quality streams to each user's specific device.

TBS8520 IPTV transcoder is equipped with 2 PCI express slots, which make it to be a flexible transcoder supporting IP, RF, HDMI or ASI inputs with the use of TBS tuner card and capture card.

With Two Giga Ethernet Ports, TBS8520 IPTV transcoder supports to transcode up to 80 SD or 32 Full HD streams simultaneously

IPTV System.

Transcode the Live TV streams or IP streams from high bitrate to low bitrate that realize huge savings in the onsite bandwidth

OTT IPTV providers (Internet TV).

Stream to both desktop and mobile devices via networks with varying bandwidth requires simultaneously transcoding to multiple resolutions and bitrates.

Transcode the incoming streams to create streams of various bitrates and resolutions for adapting varying bandwidth requires and user’s specific device, like TV, Smart Pad, Smart Phone.

TBS8520 IPTV transcoder can be easily managed through web NMS system, and has become an ideal solution for operator to provide high quality video transcoding.

Size 2U
Input interface 2xRJ45, 1000M Base-T2
2xPCI-E slot
Input
Input Signal DVBS/S2, DVBT/T2, DVBC, ATSC, ISDBT, DTMB, HDMI, ASI
Input Net Stream UDP, RTP, HTTP, HLS, Media Files
Video codecs MPEG-2, AVC / H.264, HEVC / H.265
Resolution 1920x1080P, 1920x1080i, 1280x720P, 720x576i, 720x480i, 480x576, 544x576, 640x576, 704x576
Audio codecs AAC, MP2, MP3, AC-3
Output
Output types UDP, RTP, HTTP, HLS, Media Files
Video codecs MPEG-2, AVC / H.264, HEVC / H.265
Resolution 1920x1080P, 1920x1080i, 1280x720P, 720x576i, 720x480i, 480x576, 544x576, 640x576, 704x576
Audio codecs AAC, MP3
Rate Control CBR/VBR
Transcoder up to 80 SD / 32 HD1080 AVC(H.264) streamsup to 50 SD / 26 HD1080 HEVC(H.265) streams
