| Model |
MOI Pro MAX |
| Product Name |
Professional IPTV Streaming Server |
| Size |
1U Chassis (430 * 320 * 46mm) |
| Processor |
Intel® Embedded Celeron J6412 (Quad Core, 2.6GHz) |
| Graphics |
Intel® UHD Graphics for 10th Gen Intel® Processors |
| Ethernet |
1x2.5Gbps, 1x1Gbps or 1x2.5Gbps & 2x1Gbps (optional) |
| Memory |
8G DDR4-2666 (Up to 32G ) |
| Storage |
1 x SATA 6.0 Gb/s |
| SSD |
250G M.2 SATA |
| Front Panel |
Power Button |
| Reboot Button |
| Power LED |
| HDD LED |
| Display Interface |
1 x HDMI |
| USB Port |
2x USB 2.0 |
| 2x USB 3.0 |
| SBC dimension |
128 * 104 mm |
| Operating Systems |
Rocky Linux System (default) , Linux Centos7, Ubuntu |
| Microsoft® Windows XP / Vista/ 7/8/10 |
| DVB tuner card support |
Up to 32 TV tuners (4 TV tuner PCIe cards; recommend no more than 3pcs dual CI PCIe cards such as TBS6910SE) |
| Video capture card support |
HDMI / DVB-ASI capture PCIe cards |
| Pre-installed Software |
Kylone (default) |
| Tvheadend, VDR, MuMuDVB, DVBlast, dvbdate, dvbscan, dvbdstream, dvbsnoop, scan-s2, szap-s2, tzap-t2, LIRC, telnet, ssh, ftp, samba etc. (Optional) |
| Power consumption |
72W |
| Working Environment |
Operating Temperature: 0 to 40 °C |
| Storage temperature: –20 to 70 °C |
| Relative Humidity: 5% to 90% non-condensing |
| Package Contents |
1x TBS2952 MOI Pro MAX |
| 1x AC Power Cable |
| Single Gross Weight |
11.0kg |
